How to improve the operational efficiency of cooling tower motors?
The cooling tower motor, as the core power component of the cooling tower operation, can be appropriately maintained to extend the service life of the cooling tower motor, ensure the safe operation of the cooling tower, and improve the working efficiency of the cooling tower motor.
The bearings of the cooling tower motor need to be lubricated regularly, usually every 2-3 months. When using an oil gun on a cooling tower specific motor to inject or disassemble the cooling tower specific motor at the oil nozzle, it should be noted that the oil injection amount should be one-third to one-half of the bearing chamber volume of the cooling tower motor.
To ensure the firmness and reliability of the windings and bolts of the cooling tower motor, the cables, oil seals, and dust pads of the cooling tower specific motor must be intact and undamaged. The dedicated electric motor for cooling towers should be stored in a ventilated, dry, and non corrosive place. New storage cooling tower motors should be regularly inspected for moisture, rust, icing, corrosion, and grease deterioration.
A cooling tower refers to a device that can cool water. Water undergoes heat and mass exchange with the flowing air, resulting in a decrease in water temperature. What are the causes and solutions for water leakage in the cooling tower chassis? The cooling tower chassis is the place where water is stored. Due to years of water storage, the chassis often leaks. Today, the editor will tell you the main reasons for water leakage in the cooling tower chassis:
1. After a long period of flushing, the glass fiber cloth seal at the interface between the water passing chassis plate and the plate was damaged. The reason is mostly due to excessive use of chemicals during cleaning of the cooling tower, or stepping on the bottom of the tower during cleaning, which caused the chassis to crack.
2. The sinking of the concrete foundation and uneven stress on the water passing plate result in water leakage at the interface between the plate and the bottom plate of the water passing plate. The cooling tower often overflows, causing the water tray to be filled with too much water. Excessive load-bearing structure can also lead to chassis fracture.
3. Part of the chassis leakage is due to sand holes generated during the production process of fiberglass. After a period of use, the sand holes become the main channel for leakage.
The repair method for water leakage in the cooling tower chassis is as follows: due to the large number of internal and external joints in the circulating water chassis of the cooling tower, the inner side of the pool wall is made of polyester and coated with one cloth and two coats
First, drain the water in the pool, use a spray gun, air pump, etc. to dry the pool wall, and use an angle grinder to polish it smooth. While ensuring that the base layer is dry and free of floating dust, brush a layer of polyester coating. Roll a 500 wide fiber cloth from the pool wall to the bottom surface layer, and roll it outward to a height of 100 below the top of the pool wall; After brushing once, cover the coating with non-woven fabric at intervals of one day, and then brush the coating twice with the same method as the previous coating. The inner walls of the pool wall and the outlet valve well are coated with polyester paint.
